Swift Package Manager for plugin authors

Replace plugin_name throughout this guide with the name of your plugin. The example below uses ios, replace ios with macos/darwin as applicable.

1. Turn on the Swift Package Manager feature.

2. Start by creating a directory under the ios, macos, and/or darwin directories. Name this new directory the name of the platform package.

   plugin_name/ios/
   ├── ...
   └── plugin_name/


3. Within this new directory, create the following files/directories:

   • Package.swift (file)
   • Sources (directory)
   • Sources/plugin_name (directory)
   • Sources/plugin_name/include (directory)
   • Sources/plugin_name/include/plugin_name (directory)
   • Sources/plugin_name/include/plugin_name/.gitkeep (file)
     • This file ensures the directory is committed. You can remove the .gitkeep file if other files are added to the directory.

   Your plugin should look like:

   plugin_name/ios/
   ├── ...
   └── plugin_name/
      ├── Package.swift
      └── Sources/plugin_name/include/plugin_name/
         └── .gitkeep


4. Use the following template in the Package.swift file:

   Package.swift

   swift

   // swift-tools-version: 5.9
   // The swift-tools-version declares the minimum version of Swift required to build this package.

   import PackageDescription

   let package = Package(
       // TODO: Update your plugin name.
       name: "plugin_name",
       platforms: [
           // TODO: Update the platforms your plugin supports.
           // If your plugin only supports iOS, remove `.macOS(...)`.
           // If your plugin only supports macOS, remove `.iOS(...)`.
           .iOS("12.0"),
           .macOS("10.14")
       ],
       products: [
           // TODO: Update your library and target names.
           // If the plugin name contains "_", replace with "-" for the library name
           .library(name: "plugin-name", targets: ["plugin_name"])
       ],
       dependencies: [],
       targets: [
           .target(
               // TODO: Update your target name.
               name: "plugin_name",
               dependencies: [],
               resources: [
                   // TODO: If your plugin requires a privacy manifest
                   // (e.g. if it uses any required reason APIs), update the PrivacyInfo.xcprivacy file
                   // to describe your plugin's privacy impact, and then uncomment this line.
                   // For more information, see:
                   // https://developer.apple.com/documentation/bundleresources/privacy_manifest_files
                   // .process("PrivacyInfo.xcprivacy"),

                   // TODO: If you have other resources that need to be bundled with your plugin, refer to
                   // the following instructions to add them:
                   // https://developer.apple.com/documentation/xcode/bundling-resources-with-a-swift-package
               ],
               cSettings: [
                   // TODO: Update your plugin name.
                   .headerSearchPath("include/plugin_name")
               ]
           )
       ]
   )

5. Update the supported platforms in your Package.swift file.

   Package.swift

   swift

       platforms: [
           // TODO: Update the platforms your plugin supports.
           // If your plugin only supports iOS, remove `.macOS(...)`.
           // If your plugin only supports macOS, remove `.iOS(...)`.
           .iOS("12.0"),
           .macOS("10.14")
       ],

6. Update the package, library, and target names in your Package.swift file.

   Package.swift

   swift

   let package = Package(
       // TODO: Update your plugin name.
       name: "plugin_name",
       platforms: [
           .iOS("12.0"),
           .macOS("10.14")
       ],
       products: [
           // TODO: Update your library and target names.
           // If the plugin name contains "_", replace with "-" for the library name
           .library(name: "plugin-name", targets: ["plugin_name"])
       ],
       dependencies: [],
       targets: [
           .target(
               // TODO: Update your target name.
               name: "plugin_name",
               dependencies: [],
               resources: [
                   // TODO: If your plugin requires a privacy manifest
                   // (e.g. if it uses any required reason APIs), update the PrivacyInfo.xcprivacy file
                   // to describe your plugin's privacy impact, and then uncomment this line.
                   // For more information, see:
                   // https://developer.apple.com/documentation/bundleresources/privacy_manifest_files
                   // .process("PrivacyInfo.xcprivacy"),

                   // TODO: If you have other resources that need to be bundled with your plugin, refer to
                   // the following instructions to add them:
                   // https://developer.apple.com/documentation/xcode/bundling-resources-with-a-swift-package
               ],
               cSettings: [
                   // TODO: Update your plugin name.
                   .headerSearchPath("include/plugin_name")
               ]
           )
       ]
   )

7. If your plugin has a PrivacyInfo.xcprivacy file, move it to ios/plugin_name/Sources/plugin_name/PrivacyInfo.xcprivacy and uncomment the resource in the Package.swift file.

   Package.swift

   swift

               resources: [
                   // TODO: If your plugin requires a privacy manifest
                   // (e.g. if it uses any required reason APIs), update the PrivacyInfo.xcprivacy file
                   // to describe your plugin's privacy impact, and then uncomment this line.
                   // For more information, see:
                   // https://developer.apple.com/documentation/bundleresources/privacy_manifest_files
                   .process("PrivacyInfo.xcprivacy"),

                   // TODO: If you have other resources that need to be bundled with your plugin, refer to
                   // the following instructions to add them:
                   // https://developer.apple.com/documentation/xcode/bundling-resources-with-a-swift-package
               ],

8. Move any resource files from ios/Assets to ios/plugin_name/Sources/plugin_name (or a subdirectory). Add the resource files to your Package.swift file, if applicable. For more instructions, see https://developer.apple.com/documentation/xcode/bundling-resources-with-a-swift-package.

9. Move any public headers from ios/Classes to ios/plugin_name/Sources/plugin_name/include/plugin_name.

   • If you're unsure which headers are public, check your podspec file's public_header_files attribute. If this attribute isn't specified, all of your headers were public. You should consider whether you want all of your headers to be public.

   • The pluginClass defined in your pubspec.yaml file must be public and within this directory.

10. Handling modulemap.

    Skip this step if your plugin does not have a modulemap.

    If you're using a modulemap for CocoaPods to create a Test submodule, consider removing it for Swift Package Manager. Note that this makes all public headers available through the module.

    To remove the modulemap for Swift Package Manager but keep it for CocoaPods, exclude the modulemap and umbrella header in the plugin's Package.swift file.

    The example below assumes the modulemap and umbrella header are located in the ios/plugin_name/Sources/plugin_name/include directory.

    Package.swift

    swift

    .target(
        name: "plugin_name",
        dependencies: [],
        exclude: ["include/cocoapods_plugin_name.modulemap", "include/plugin_name-umbrella.h"],

    If you want to keep your unit tests compatible with both CocoaPods and Swift Package Manager, you can try the following:

    Tests/TestFile.m

    objc

    @import plugin_name;
    @import plugin_name.Test;
    #if __has_include(<plugin_name/plugin_name-umbrella.h>)
      @import plugin_name.Test;
    #endif

    If you would like to use a custom modulemap with your Swift package, refer to Swift Package Manager's documentation.

11. Move all remaining files from ios/Classes to ios/plugin_name/Sources/plugin_name.

12. The ios/Assets, ios/Resources, and ios/Classes directories should now be empty and can be deleted.

13. If your header files are no longer in the same directory as your implementation files, you should update your import statements.

    For example, imagine the following migration:

    • Before:

      ios/Classes/
      ├── PublicHeaderFile.h
      └── ImplementationFile.m


    • After:

      ios/plugin_name/Sources/plugin_name/
      └── include/plugin_name/
         └── PublicHeaderFile.h
      └── ImplementationFile.m


    In this example, the import statements in ImplementationFile.m should be updated:

    Sources/plugin_name/ImplementationFile.m

    objc

    #import "PublicHeaderFile.h"
    #import "./include/plugin_name/PublicHeaderFile.h"

14. If your plugin uses Pigeon, update your Pigeon input file.

    pigeons/messages.dart

    dart

    javaOptions: JavaOptions(),
    objcHeaderOut: 'ios/Classes/messages.g.h',
    objcSourceOut: 'ios/Classes/messages.g.m',
    objcHeaderOut: 'ios/plugin_name/Sources/plugin_name/messages.g.h',
    objcSourceOut: 'ios/plugin_name/Sources/plugin_name/messages.g.m',
    copyrightHeader: 'pigeons/copyright.txt',

    If your objcHeaderOut file is no longer within the same directory as the objcSourceOut, you can change the #import using ObjcOptions.headerIncludePath:

    pigeons/messages.dart

    dart

    javaOptions: JavaOptions(),
    objcHeaderOut: 'ios/Classes/messages.g.h',
    objcSourceOut: 'ios/Classes/messages.g.m',
    objcHeaderOut: 'ios/plugin_name/Sources/plugin_name/include/plugin_name/messages.g.h',
    objcSourceOut: 'ios/plugin_name/Sources/plugin_name/messages.g.m',
    objcOptions: ObjcOptions(
      headerIncludePath: './include/plugin_name/messages.g.h',
    ),
    copyrightHeader: 'pigeons/copyright.txt',

    Run Pigeon to re-generate its code with the latest configuration.

15. Update your Package.swift file with any customizations you might need.

    1. Open the ios/plugin_name/ directory in Xcode.

    2. In Xcode, open your Package.swift file. Verify Xcode doesn't produce any warnings or errors for this file.

    3. If your ios/plugin_name.podspec file has CocoaPods dependencys, add the corresponding Swift Package Manager dependencies to your Package.swift file.

    4. If your package must be linked explicitly static or dynamic (not recommended by Apple), update the Product to define the type:

       Package.swift

       swift

       products: [
           .library(name: "plugin-name", type: .static, targets: ["plugin_name"])
       ],

    5. Make any other customizations. For more information on how to write a Package.swift file, see https://developer.apple.com/documentation/packagedescription.

16. Update your ios/plugin_name.podspec to point to new paths.

    ios/plugin_name.podspec

    ruby

    s.source_files = 'Classes/**/*.{h,m}'
    s.public_header_files = 'Classes/**/*.h'
    s.module_map = 'Classes/cocoapods_plugin_name.modulemap'
    s.resource_bundles = {'plugin_name_privacy' => ['Resources/PrivacyInfo.xcprivacy']}
    s.source_files = 'plugin_name/Sources/plugin_name/**/*.{h,m}'
    s.public_header_files = 'plugin_name/Sources/plugin_name/include/**/*.h'
    s.module_map = 'plugin_name/Sources/plugin_name/include/cocoapods_plugin_name.modulemap'
    s.resource_bundles = {'plugin_name_privacy' => ['plugin_name/Sources/plugin_name/PrivacyInfo.xcprivacy']}

17. Update loading of resources from bundle to use SWIFTPM_MODULE_BUNDLE:

    objc

    #if SWIFT_PACKAGE
       NSBundle *bundle = SWIFTPM_MODULE_BUNDLE;
     #else
       NSBundle *bundle = [NSBundle bundleForClass:[self class]];
     #endif
     NSURL *imageURL = [bundle URLForResource:@"image" withExtension:@"jpg"];

18. If your ios/plugin_name/Sources/plugin_name/include directory only contains a .gitkeep, you'll want update your .gitignore to include the following:

    .gitignore

    text

    !.gitkeep

    Run flutter pub publish --dry-run to ensure the include directory is published.

19. Commit your plugin's changes to your version control system.

20. Verify the plugin still works with CocoaPods.

    1. Turn off Swift Package Manager:

       sh

       flutter config --no-enable-swift-package-manager

    2. Navigate to the plugin's example app.

       sh

       cd path/to/plugin/example/

    3. Ensure the plugin's example app builds and runs.

       sh

       flutter run

    4. Navigate to the plugin's top-level directory.

       sh

       cd path/to/plugin/

    5. Run CocoaPods validation lints:

       sh

       pod lib lint ios/plugin_name.podspec  --configuration=Debug --skip-tests --use-modular-headers --use-libraries

       sh

       pod lib lint ios/plugin_name.podspec  --configuration=Debug --skip-tests --use-modular-headers

21. Verify the plugin works with Swift Package Manager.

    1. Turn on Swift Package Manager:

       sh

       flutter config --enable-swift-package-manager

    2. Navigate to the plugin's example app.

       sh

       cd path/to/plugin/example/

    3. Ensure the plugin's example app builds and runs.

       sh

       flutter run

    4. Open the plugin's example app in Xcode. Ensure that Package Dependencies shows in the left Project Navigator.

22. Verify tests pass.

    • If your plugin has native unit tests (XCTest), make sure you also update unit tests in the plugin's example app.

    • Follow instructions for testing plugins.
